Multiquip MVH208GH, 8,318 lbs cf, Honda GX-240 Gas, 20" wide plate
Multiquip’s Mikasa Reversible Plate Compactors are the ideal high-production machines for efficient compaction of sand, gravel and cohesive soils.
-Reliable Honda GX240 engine.
-Fold-out front cover for easy access to all maintenance points.
-Hour/Tachometer to measure machine hour usage and engine RPM.
-Cyclonic pre-cleaner to capture most airborne contaminants for engine protection and extended service life.
-Heavy-duty shock mounts to withstand harsh operating environment while reducing vibration to the operator and helping to extend component life.
-Hydraulic controls enables operator to easily switch direction from forward to reverse while also allowing for spot compaction.
-Rugged base plate manufactured from high strength steel for top performance and featuring open design for easy cleanup.
-Steel frame protective guard with fully integrated cage protects the engine from loose debris or dirt while serving as a lifting bar for easy portability.
-Low profile base plate lowers the center of gravity dramatically improving travel speed.
Unit Specifications
Centrifugal Force - 8318 lbf 37 kN
Exciter Speed - 5200 VPM
Plate Size - 28.3 x19.7 in; 720 x 500 mm
Max Forward Speed Per Min. - 85 ft 26 m
Fuel Consumption Per Hour - .67 gal 2.54 L
Dimensions & Weights
Overall Length - 51.6 in 1311 mm
Overall Width - 19.7 in 500 mm
Overall Height - 39.2 in 996 mm
Operating Weight - 463 lb 210 kg
